EN - GS 2669 RT | Scissor lifts

| Machines | Scissor lifts | EN – GS 2669 RT

GS 2669 RT

Rent a machine

Download documents

Diesel powered scissor lift provides a distinct strategic advantage outdoors

Our diesel scissor lifts are recommended for outdoor use due to the fuel consumption. If you need it for outdoor loading docks or work outside, this is the right choice.
You don’t have to give up the benefits and convenience of scissor lifts outdoors. With scissor lifts that can be controlled from the platform, your staff can concentrate on their tasks while changing positions.
Some of our outdoor diesel scissor lifts are designed to remain stable and safe in the most varied ground conditions, thanks to their larger wheels, to protect the safety of your colleagues. They can usually be lifted higher, so they have even sturdier handrails and safety guards to allow you to work safely.

Gallery

Benefits of using

1.

The machine also excels on uneven terrain with positive traction control, which can increase productivity on demanding outdoor jobsites.
2.

The Genie GS 2669 RT diesel scissor lift has special foam-filled tires that are specially designed to make working on difficult terrain literally smoother.
3.

The four-wheel drive and positive traction control are extremely useful on rough terrain with climbs.
4.

The patented oscillating axle automatically adjusts the position of the axle according to the ground conditions.
5.

The Genie diesel scissor lift work platform is equipped with a 1.52 metre sliding extension to maximise the working area.
6.

The working platform allows safe and efficient working at a height of 9.7 metres.
7.

The 680 kg capacity scissor lift can be operated with a user-friendly Smart Link control and diagnostic system.
8.

Working on the platform of the GS 2669 RT diesel scissor lift with lockable guard rail is supported by AC power supply.
9.

Safety at height is ensured by a tilt sensor, a descent alarm, a load sensor and flashing LED lights and horn.

Tank capacity

The fuel tank can hold 37.9 litres of diesel.

Maximum tank capacity required to operate the hydraulics: 68.1 litres.

Technical data

We have summarized the shift data for the Genie GS 2669 RT diesel scissor lift. If there is data you need but don’t see it in the specifications, please contact us!

Working height: 9.70 metres

Platform height: 7.70 metres

Load capacity with operator, basket retracted: 680 kg

Basket only: 544 kg

Extension only: 136 kg

Maximum occupancy: 4 people

Platform extensibility: 1.52 metres

Maximum platform length: 4.31 metres

Platform width: 1.60 metres

Platform length: 2.79 metres

Overall width: 1.75 metres

Machine length with transport skids: 3.76 metres

Length with outriggers: 3.76 metres

Overall width: 1,75 metres

Overall height (rail folded down): 1.92 metres

Overall height (with guardrail): 2.59 metres

Overall weight with outriggers: 3768 kg / may vary depending on equipment

Gradeability: 40%

Wheelbase: 2.29 metres

Ground Clearence: 0.24 metres

Power: diesel

Turning radius / external: 4.60 metres

Use: outdoor

Downloadable documents

Specification in English

Instructions for use in Hungarian

English language spare parts catalogue
