MRT 3570 ES 360

A 3-in-1 helper on the job: it can be used as a telehandler, crane and work platform, and can be complemented with a wide range of compatible accessories.

Comfortable driving, optimum handling and even greater work safety come with the Manitou MRT 3570 ES! Thanks to its 360-degree rotation, telescopic boom system and load lifting capacity of up to 7,000 kilograms, it can be used for construction and material handling tasks.

Heavy duty rotary telehandler, ideal for construction and industrial applications

As a telescopic handler, crane and work platform, a range of compatible attachments are available for versatility and performance on the jobsite. The 360° rotation of the pedestal and the exceptional view from the ergonomic cab allow you to perform operations more easily without having to move the machine. The pentagonal design of the boom allows precise movement and stability of the machine by automatically levelling the outriggers. With the electronic suspension, the MRT 3570 ES is even more comfortable to drive, providing lateral and longitudinal slope correction.

Gallery

Benefits of using

The pentagonal cross-section of the boom allows precise movement and stability of the machine with automatic boom levelling. The electronic suspension makes the MRT 3570 ES even more comfortable to drive and allows lateral and longitudinal tilt correction. Equipped with intelligent functions for optimum handling and safety, the MRT 3570 ES is the best machine for complex tasks!

  • 1.

    Complementable by a wide range of compatible accessories

  • 2.

    Triple telescopic, individual or simultaneous stabilisation controls

  • 3.

    Four-wheel drive with “crab” mode

Tank capacity

  • The fuel tank can hold 320 litres of diesel.
  • The maximum tank capacity required to operate the hydraulics is 300 litres.
  • The engine oil has a tank capacity of 13 litres.

Technical data

We have summarized the technical data of the Manitou MRT 3570 ES 360 rotating telehandler. If there is any data you need but you don’t see it in the technical data, please contact us!

Lifting height: 34.70 metres

Load capacity: 7 000 kg

Max. outreach: 28.00 metres

Overall height: 3.26 metres

Operators: 1 person

Machine width: 2.5 metres

Overall width with outriggers extended: 7.40 metres

Machine length with forks: 10.06 metres

Overall length at outriggers: 6.50 metres

Overall height: 3.26 metres

Overall weight (may vary depending on equipment): 24 000 kg

Wheelbase: 3.75 metres

Ground Celarence: 0.39 metres

Power: diesel

Maximum speed: 40 km/h

Tires: standard

Gradeability: 29%

Use: outdoor
